Charts

Charts is a multi-library chart package to create interactive charts using laravel.

Libraries & Types

Charts include the following libraries & types by default:

ChartJS chartjs
- Area Chart area
- Line Chart line
- Bar Chart bar
- Pie Chart pie
- Donut / Doughnut Chart donut
Highcharts highcharts
- Area Chart area
- Line Chart line
- Bar Chart bar
- Pie Chart pie
- Donut / Doughnut Chart donut
- Geo Chart geo
Google Charts google
- Area Chart area
- Line Chart line
- Bar Chart bar
- Pie Chart pie
- Donut / Doughnut Chart donut
- Geo Chart geo
Chartist chartist
- Area Chart area
- Line Chart line
- Bar Chart bar
- Pie Chart pie
- Donut / Doughnut Chart donut
FusionCharts fusioncharts
- Area Chart area
- Line Chart line
- Bar Chart bar
- Pie Chart pie
- Donut / Doughnut Chart donut
Morris JS morris
- Area Chart area
- Line Chart line
- Bar Chart bar
- Donut / Doughnut Chart donut

Installation

Video Tutorial

To install charts use composer

Download

composer require consoletvs/charts

Add service provider & alias

Add the following service provider to the array in: config/app.php

ConsoleTVs\Charts\ChartsServiceProvider::class,

Add the following alias to the array in: config/app.php

'Charts' => ConsoleTVs\Charts\Charts::class,

Publish the assets

php artisan vendor:publish --tag=charts_config
php artisan vendor:publish --tag=charts_assets --force

Default Settings

The file in: config/charts.php contains an array of settings, you can find the default settings in there.

Usage

Example Controller:

<?php

namespace App\Http\Controllers;

use Illuminate\Http\Request;

use App\Http\Requests;
use Charts;

class TestController extends Controller
{
    public function index()
    {
		$chart = Charts::new('line', 'highcharts')
			->setTitle('My nice chart')
			->setLabels(['First', 'Second', 'Third'])
			->setValues([5,10,20])
			->setDimensions(1000,500)
			->setResponsive(false);
		return view('test', ['chart' => $chart]);
    }
}

Example View:

<!DOCTYPE html>
<html lang="en">
    <head>
        <meta charset="utf-8">
        <meta http-equiv="X-UA-Compatible" content="IE=edge">
        <meta name="viewport" content="width=device-width, initial-scale=1">

        <title>My Charts</title>

		{!! Charts::assets() !!}

    </head>
    <body>
        <center>
			{!! $chart->render() !!}
		</center>
    </body>
</html>

Chart Examples

Pie

Note: highcharts can't change the color of this chart. Well it can but it's complicated, so I leave it here.

Charts::new('pie', 'highcharts')
	->setTitle('My nice chart')
	->setLabels(['First', 'Second', 'Third'])
	->setValues([5,10,20])
	->setDimensions(1000,500)
	->setResponsive(false);

Donut / Doughnut

Note: highcharts and chartist can't change the color of this chart. Well they can but it's complicated, so I leave it here.

Charts::new('donut', 'highcharts')
	->setTitle('My nice chart')
	->setLabels(['First', 'Second', 'Third'])
	->setValues([5,10,20])
	->setDimensions(1000,500)
	->setResponsive(false);

Line

Charts::new('line', 'highcharts')
	->setTitle('My nice chart')
	->setElementLabel('My nice label')
	->setLabels(['First', 'Second', 'Third'])
	->setValues([5,10,20])
	->setDimensions(1000,500)
	->setResponsive(false);

Area

Charts::new('area', 'highcharts')
	->setTitle('My nice chart')
	->setElementLabel('My nice label')
	->setLabels(['First', 'Second', 'Third'])
	->setValues([5,10,20])
	->setDimensions(1000,500)
	->setResponsive(false);

Bar

Note: highcharts can't change the color of this chart. Well it can but it's complicated, so I leave it here.

Charts::new('bar', 'highcharts')
	->setTitle('My nice chart')
	->setElementLabel('My nice label')
	->setLabels(['First', 'Second', 'Third'])
	->setValues([5,10,20])
	->setDimensions(1000,500)
	->setResponsive(false);

Geo

Note: The labels must have the country codes, not the name.

Note 2: To add color to the chart, you'll need to provide an array of at least 2 colors. The first is the min and the second the max.

Charts::new('geo', 'highcharts')
	->setTitle('My nice chart')
	->setElementLabel('My nice label')
	->setLabels(['ES', 'FR', 'RU'])
	->setColors(['#C5CAE9', '#283593'])
	->setValues([5,10,20])
	->setDimensions(1000,500)
	->setResponsive(false);

Charts Functions

new()

Returns a new chart instance, if no library is specified, the default one will be used.
```
Charts::new('line'');
Charts::new('line', 'highcharts');
```

assets()

Returns all the assets to generate the graphs.

<?php echo Charts::assets(); ?>

// using blade
{!! Charts::assets() !!}

libraries()

Returns an array of all the libraries available (can be filtered)

// Return all the libraries available
print_r(Charts::libraries());

// Return all the libraries available for the line chart
print_r(Charts::libraries('line'));

types()

Returns an array of all the chart types available (can be filtered)

// Return all the chart types available
print_r(Charts::types());

// Return all the chart types available for the highcharts library
print_r(Charts::libraries('highcharts'));

Available Chart Settings:

setType()

Set the chart type after creation (Example: from line to pie)
```
Charts::new('line', 'highcharts')->setType('pie');
```
setLibrary()

Set the chart library after creation (Example: from highcharts to google)
```
Charts::new('line', 'highcharts')->setLibrary('google');
```

setLabels()

The labels of the chart

Charts::new('line', 'highcharts')->setLabels(['First', 'Second', 'Third']);

setValues()

The values of the chart respectively

Charts::new('line', 'highcharts')->setValues([10, 50, 100]);

setElementLabel()

The element label for line / bar / geo charts

Charts::new('line', 'highcharts')->setElementLabel('Total Views');

setTitle()

The chart title

Charts::new('line', 'highcharts')->setTitle('My Chart');

setColors()

The colors of the charts respectively

Charts::new('line', 'highcharts')->setColors(['#ff0000', '#00ff00', '#0000ff']);

setWidth()

The chart width if non-responsive

Charts::new('line', 'highcharts')->setWidth(1000);

setHeight()

The chart height if non-responsive

Charts::new('line', 'highcharts')->setHeight(500);

setDimensions()

The chart dimensions (shortcut to set width, height with one funcion)
```
Charts::new('line', 'highcharts')->setHeight(1000, 500);
```
setResponsive()

Set if the chart is responsive or not. If not, the chart dimensions will be used.
```
Charts::new('line', 'highcharts')->setResponsive(false);
```

settings()

Return the chart settings

print_r(Charts::new('line', 'highcharts')->settings());

render()

Render the chat!

echo Charts::new('line', 'highcharts')->setLabels(['One', 'Two'])->setValues([10, 20])->render();

Extend your way!

You can create your own Charts by forking this repository. The src/Templates folder contains all the current charts, but you can add yours like this:

Create a new file

Create a new file, the syntax is: library.type.php

if your chart library is called: mylib and your template is for the line chart: line Then you create a file like this: mylib.line.php

To call it later, just use:

$chart = Charts::new('line', 'mylib');

You have plenty of examples to see how to put the data so just take a closer look at all the included templates before doing yours!
