g2dj's Introduction

G2Dj

alt tag alt tag alt tag alt tag

Description:

asdf asdf asdf

Crossplatform game engine in Java & OpenGLES. Designed for 2D, low-fi graphics, but is capable of 3D perspective rendering for "2.5D" projects. Builds for Mac/Linux/Windows and Android.

Games are programmed against an Entity Component System, the components used by the game depend on a set of engine systems. While systems can be added arbitarily to G2Dj, there are a few that are present out of the box:

Graphics

  • 3D Forward Renderer
  • Resource managers for shaders, textures, models
  • Supports OpenGLES 2.0 standard
  • Basic 2D game shaders & programmable shader interface
  • Unicode Text renderer supporting the full Basic Multilingual Plane
  • Tilegrid and spritesheet renderers

Physics2D

  • Rigidbodies, colliders and trigger areas
  • Colliders can be built from rectangles, circles or complex shapes made from sets of vertexes or primitives
  • When Rigidbodies collide with colliders or enter trigger areas, OnCollision and OnTigger callbacks on the Rigidbody's Gameobject are invoked
  • Implementation based on jbox2D

Audio

  • 3D sound system based on OpenAL
  • Supports wav, Ogg Vorbis, FLAC files

Math

  • 2D and 3D linear algebra
  • 2-4d Vectors, Mat4x4

Input

  • Mouse
  • Keyboard
  • USB Gamepads
  • Touchscreen handler

Time, Files, Debug.

Building the engine:

Desktop

  • Add the correct native libs for JOGL, JOAL and JInput to the project (Win32/64, Mac, Linux32/64).
  • Run PreprocessorWizard.pl with #define DESKTOP
  • Open the NetBeans project file and build G2Dj.

Mobile

  • Run PreprocessorWizard.pl with #define ANDROID
  • Open the Android Studio project file and build G2Dj.

Creating a game:

Games are written against an ECS. The ECS is comprised of 3 basic class types: Scene, GameObject, Component. Scenes define a 3D space with a customizable set of capabilities (rendering, physics, etc.). A game can be made of any number of scenes and can be run concurrently. GameObjects have a set of Components. Components define behaviours for their parent GameObjects.

public static void main(String[] args)
{
    //Engine entry point
    Engine.init(new Game()
    {
        @Override public void init(){initMyGame();}

    });

}

public static void initMyGame()
{
    //Load some textures
    Graphics.loadFromResource("/Resources/Cloud.png");
    Graphics.loadFromResource("/Resources/brick.png");

    //Create a scene
    WeakReference<Scene> mainScene = Engine.createScene("Main");

    //Create the player game object
    {
        WeakReference<GameObject> aGameObject = mainScene.get().addGameObject();
        aGameObject.get().setName("Player1");

        Mesh aMesh = (Mesh)aGameObject.get().addComponent(Mesh.class); //add a mesh
        aMesh.setTexture("_Texture", "awesome.png"); //give the mesh a texture

        PlayerController aPC = (PlayerController)aGameObject.get().addComponent(PlayerController.class);
        aPC.getTransform().get().setRotation(new Vector3(0,0,45));
        aPC.getTransform().get().setPosition(new Vector3(0,0,+0.5f));

    }

    //Create the camera
    {
        WeakReference<GameObject> theCamera = mainScene.get().addGameObject();
        theCamera.get().setName("Camera");
        theCamera.get().getTransform().get().setPosition(new Vector3(-1,0,2));
        theCamera.get().getTransform().get().setRotation(new Vector3(0,45,0));

        theCamera.get().addComponent(CameraController.class);
        theCamera.get().addComponent(Camera.class);

    }

}

Creating a custom component

//Require that this GameObject's scene have 2D physics capability
@RequireSceneGraphs({Physics2DSceneGraph.class})

//Require that this GameObject have a rigidbody and a collider
@RequireComponents({Camera.class,Rigidbody.class,CircleCollider.class})

public class PlayerController extends grimhaus.com.G2Dj.Type.Engine.Component
{
    private static final float s_Speed = 0.1f;
    private final Vector3 inputBuffer = new Vector3();
    private final Vector3 rotationBuffer = new Vector3();
    private final Vector3 scaleBuffer = new Vector3();

    @Override
    protected void initialize() {}

    @Override
    protected void update()
    {
        //Translation
        {
            inputBuffer.setInPlace(0);

            //Keyboard input
            if (Input.getKey(KeyCode.J))
                inputBuffer.x-=s_Speed;

            if (Input.getKey(KeyCode.L))
                inputBuffer.x+=s_Speed;

            if (Input.getKey(KeyCode.I))
                inputBuffer.z-=s_Speed;

            if (Input.getKey(KeyCode.K))
                inputBuffer.z+=s_Speed;

            getTransform().get().translate(inputBuffer);

        }

        //Rotation
        {
            rotationBuffer.setInPlace(0);

            //Keyboard input
            if (Input.getKey(KeyCode.U))
                rotationBuffer.y +=0.1f;

            if (Input.getKey(KeyCode.O))
                rotationBuffer.y -=0.1f;

            getTransform().get().rotate(rotationBuffer);

        }

        //Scale
        {
            scaleBuffer.setInPlace(0);

            if (Input.getKey(KeyCode.R))
                scaleBuffer.addInPlace(0.01f);

            if (Input.getKey(KeyCode.F))
                scaleBuffer.addInPlace(-0.01f);

            getTransform().get().scale(scaleBuffer);

        }

    }

    @Override protected void OnComponentAdded(Component aComponent) {}
    @Override protected void OnComponentRemoved(Component aComponent) {}

}

Libraries used:

  • JOGL - OpenGL support on Desktop builds
  • JOAL - OpenAL
  • jGLM - Reference material for Math.Mat4x4
  • jbox2D - Implementation dependency for Physics2D
  • JInput - Gamepad support on Desktop builds
  • J-Ogg - Ogg Vorbis and FLAC decoder

Tools used:
